Complete Assembled Scale PHAT Rear Axle Version 2 for D90/D110 Red
Complete Rear Scale PHAT™ Axles for the Team Raffee Co. D90/D110 or Gelande 2 D90, TF2. Weighs a whopping 240 grams rear.
Scale PHAT Axle Housing
Heavy duty one piece rear drive shaft
Heavy duty helical ring and pinion bevel gears (27/10T)
Low Profile PHAT Truss
Aluminum 12mm wheel hex
This version 2 has updated helical gears and PHAT™ Scale truss. Helical gears now using 27/10T, with bigger teeth and beefier material than Version 1.
*MUST SHIM AXLE PROPERLY BEFORE USE*
When you receive the axles, take them aparts and shim them properly and make sure the gears are lined up smooth. Turn the input shaft and you should feel no clicks or bumps, it should be smooth.
Shim Sizes: 8mm ring gear 5mm pinion gear.
Pin to pin width: 175mm
Build your own custom scale rigs with these performance based D90/D110 Scale PHAT™ Axles. If you are looking for a solid heavy duty axle, this one is for you.
Interchangeable diff covers with RC4WD ARB diff cover.
Replacement bevel gear set: BRQ90332BK
